Flemish Eye Steel Swaging Sleeves S-505 for Wire Rope (1/4"–6")

Features and Specifications:
Product Code: S-505
Wire Rope Size Range: 1/4" – 6"
Material: High-strength forged steel
Finish: Galvanized or self-colored
Process: Forging + Heat Treatment + Sand Blasting
Applications: Wire rope splicing, Flemish eye termination, lifting, towing, and marine rigging
Manufacturing Tolerance: Consistent dimensional precision through automated marking and quality control
Weight Range: 2.27 – 12,300 kg per 100 pcs

Advantages:
Uniform mechanical strength after swaging
Excellent resistance to wear and corrosion
Wide range of sizes suitable for different wire rope diameters
Smooth finish reduces wire rope abrasion
Compatible with manual or hydraulic swaging machines

The Flemish eye steel swaging sleeves S-505 provide a reliable connection solution for wire rope assemblies where safety, precision, and strength are essential.

Flemish eye steel swaging sleeves (S-505) are precision-engineered fittings used to form Flemish eye terminations on steel wire ropes. Manufactured through advanced in-house forging, heat treatment, and sandblasting processes, these sleeves provide reliable mechanical strength and consistent performance for load-bearing applications.

Each sleeve is produced with strict dimensional accuracy, covering wire rope sizes from 1/4 inch to 6 inches. Available in both galvanized and self-colored finishes, the S-505 series offers enhanced corrosion resistance and long-term durability for use in marine, lifting, and rigging environments.

The swaging sleeves are designed to achieve uniform compression after swaging, maintaining the structural integrity of the wire rope under tension. Their robust construction makes them suitable for heavy-duty applications such as cranes, construction hoisting systems, offshore operations, and material handling.
