Steel Oval Sleeves for Wire Rope (Low Carbon Steel, 5/16"–1-1/4")

Features and Specifications:
Material: Specially processed low-carbon steel
Suitable Wire Rope Constructions: 6x19, 6x37, IPS or XIP (EIP), RRL, FC, or IWRC
Size Range: 5/16" – 1-1/4"
Shape: Oval
Process: Precision machining and controlled swaging
Surface: Bright steel finish
Applications: Wire rope splicing, eye termination, rigging connection, lifting and hoisting systems
Weight Range: 13 – 384 kg per 100 pcs

Advantages:
Strong and reliable compression after swaging
Smooth internal surface reduces abrasion on wire rope
Consistent dimensional accuracy for repeatable assembly quality
Compatible with hydraulic or mechanical swaging machines
Economical solution for wire rope terminations

The steel oval sleeves provide a safe and durable method for assembling wire rope loops, combining strength, simplicity, and cost efficiency for industrial and marine applications.

Steel oval sleeves are precision-fabricated fittings designed for forming secure mechanical connections on wire ropes. Manufactured from specially processed low-carbon steel, these sleeves provide excellent ductility and uniform swaging performance. They are typically used for creating loop or eye terminations in wire rope assemblies.

The sleeves are suitable for 6x19 or 6x37 constructions, IPS or XIP (EIP), RRL, FC, or IWRC wire ropes. Available in a wide range of sizes from 5/16 inch to 1-1/4 inch, the oval design provides balanced strength and reliable compression after swaging.

Each sleeve undergoes strict dimensional control to ensure a tight fit and stable performance under working loads. The smooth inner bore minimizes rope wear and enhances the mechanical holding force, making these sleeves widely used in lifting, towing, rigging, and construction applications.
